Schwarzbrenner 45 Disc Edition Vorderrad

Für Preisinformationen .

Bremsscheibenaufnahme:

Einbaubreite:

Endkappen:

Farbe:

  • LKVSB45DedKHCl24BeaSt12mmAluDLNipUPSWbck
  • 4062266214566
Are you looking for a disc carbon wheel at the best price that has also been developed with all... mehr
Produktinformationen "Schwarzbrenner 45 Disc Edition Vorderrad"

Are you looking for a disc carbon wheel at the best price that has also been developed with all the expertise of Tune? Then the Schwarzbrenner 45 Disc Edition is for you! The wheel is equipped with our best-selling KillHill hub, which is now available for the popular Centerlock* disc-brake mount! The hub is CNC machined in our factory from aerospace grade aluminium, thus demonstrating increased fatigue strength and low weight. The anodising ensures a great look and prevents corrosion, even under the toughest circumstances. Assembled and adjusted by hand in Buggingen, Germany, the Schwarzbrenner 45 Disc Edition boasts the highest quality standards—guaranteed! The geometry has been optimised for a balanced, stiff wheel. A braiding robot in Germany makes the carbon rim, which confers extra reliability and great impact resistance. The rim has appreciable lateral rigidity, as well as a highly contained weight that is ideal for swallowing up kilometres on hilly profiles. The rim also has a NACA profile with 45mm height, which provides a great aerodynamic performance. Also, the rim is very stiff due to the D-Light spokes that are two times butted and have the best price/weight ratio. The Schwarzbrenner 45 Disc Edition has been designed for those who cannot choose between a ride high in altitude or a flat ride. Why not do both with this Swiss (sorry, German) army knife of a wheel? Indeed, it is the perfect wheel to attack the Alps with full confidence!

Technical data

weight from: 674g
hub type: KillHill CL 24 holes with Aluminium Endcaps and standard bearings
spokes: SAPIM D-Light Butted Black Spokes
max. spoke tension 1100N
max. rider weight: 100kg
max.system weight: 110kg
rim inner width: 17mm
rim outer width: 27mm
rim height: 45mm
rim standard: 700c clincher, 622 x 17mm
tubeless ready: yes
mandatory rim tape: 18mm Tune Tape, Tubeless Compatible
mandatory valve type: 60mm Tune Tubeless Valve or similar type
tyres and max.pressure: 23mm/8,5bar - 25mm/8bar - 28mm/7,5bar - 33mm/5bar
nipples: SAPIM Anodized, double square, Polyax, Secure Lock, 16mm
brake interface: Centerlock* disc-brake interface
colours: for hubs, nipples and Tune decals, available only in Black
scope of delivery: wheel and packaging
Notes Screw on the Centerlock* lockring and tighten it with max. 40Nm
for more information please refer to the user manual
*Center Lock rotor mounting system licensed by Shimano
